Vikimage 5MP MIPI Camera Module
Model: FUT-OV5640-SPI-69AF
The camera module features a 1/4″ OV5640 image sensor with 1.4 µm x 1.4 µm pixels and a 5.0 MP resolution (2592H x 1944V). The lens has a 3.29mm effective focal length and an f/2.8 aperture, with auto-focus capability. It uses an electronic rolling shutter and operates in temperatures ranging from -40°C to +95°C. The module size is 15.6mm x 6.5mm x 3.88mm.
- 5 Megapixel 2592H x 1944V
- Module Size: 15.6mm x 6.5mm x 3.88mm
- Electronic Rolling shutter
- Fixed Focus
|
SPECIFICATION |
|
|
Image Sensor |
1/4″ 0V5640 |
|
Pixel Size |
1.4 µm x 1.4 µm |
|
Resolution |
5.0 Megapixel 2592H x 1944V |
|
Interface |
SPI |
|
FOV |
68.7 degree |
|
Lens |
EFL: 3.29mm F/NO:2.8mm |
|
Focus type |
Auto Focus |
|
Shutter type |
Electronic Rolling shutter |
|
Operating Temp |
-40°C ~ +95°C |
|
Module Size |
15.6mm x 6.5mm x 3.88mm |
