Vikimage 5MP MIPI Camera Module OV5693
Model: FUT-OV5695-MIPI-84FF
The camera module features a 1/4″ OV5695 image sensor with 1.4 µm x 1.4 µm pixels and a 5.0 MP resolution (2592H x 1944V). The lens has a 2.51mm effective focal length and an f/2.0 aperture, with fixed focus. The module utilizes an electronic rolling shutter and operates within a temperature range of -30°C to +70°C. Its compact dimensions are 15.6mm x 6.5mm x 3.88mm.
- 5 Megapixel 2592H x 1944V
- Module Size: 46mm x 2.5mm
- Electronic Rolling shutter
- Fixed Focus
|
SPECIFICATION |
|
|
Image Sensor |
1/4″ 0V5695 |
|
Pixel Size |
1.4 µm x 1.4 µm |
|
Resolution |
5.0 Megapixel 2592H x 1944V |
|
Interface |
MIPI |
|
FOV |
84 degree |
|
Lens |
EFL: 2.51mm F/NO:2.0mm |
|
Focus type |
Fixd Focus |
|
Shutter type |
Electronic Rolling shutter |
|
Operating Temp |
-30°C ~ +70°C |
|
Module Size |
15.6mm x 6.5mm x 3.88mm |
