Vikimage 5MP USB2.0 Camera Module OV5693
Model: FUT-OV5693-USB-66AF
The camera module features a 1/4″ OV5693 image sensor with 1.4 µm x 1.4 µm pixels and a 5.0 MP resolution (2592 x 1944). The lens has a 3.4mm effective focal length and an f/2.8 aperture, with auto-focus capability. It uses an electronic rolling shutter and operates in temperatures ranging from -30°C to +70°C. The module size is 67mm x 8.5mm x 5.6mm.
- 5 Megapixel 2592 x 1944
- Module Size: 67mm x 8.5mm x 5.6mm
- Electronic Rolling shutter
- Auto Focus
|
SPECIFICATION |
|
|
Image Sensor |
1/4″ OV5693 |
|
Pixel Size |
1.4um(H) x 1.4um(V) |
|
Resolution |
5.0 Megapixel 2592 x 1944 |
|
Interface |
USB |
|
FOV |
65.5 degree |
|
Lens |
EFL: 3.4mm F/NO:2.8mm |
|
Focus type |
Auto Focus |
|
Shutter type |
Electronic Rolling shutter |
|
Operating Temp |
-30°C ~ +70°C |
|
Module Size |
67mm x 8.5mm x 5.6mm |
